Hot Water Storage Tank | Jacketed Electric Heating for Process Cleaning

Overview

The Hot Water Storage Tank is a purpose-built utility vessel that supplies heated water for CIP and gelatin melting tanks and preparation equipment between batches. Equipped with electric heating elements and a fully insulated double-wall jacket, it maintains water at 80–100 °C on standby - ensuring hot cleaning water is immediately available when required for CIP or manual cleaning cycles.

Designed as the companion hot water source for water-jacketed gelatin melting systems, the Hot Water Storage tank supports recirculating hot water loops that reduce overall energy consumption compared to point-of-use heating.

Key Operating Benefits

Ready Hot Water on Demand

Maintains set temperature continuously - no waiting for water to heat before starting equipment cleaning cycles

Recirculating Energy Efficiency

Hot water circulates through the cleaning loop and returns to the tank, retaining heat and reducing reheating energy compared to single-pass heating

Consistent Cleaning Temperature

Maintains stable water temperature throughout the cleaning cycle - supports consistent cleaning results for validated wash procedures

Construction & Features

Double-wall insulated construction - reduces heat loss and extends temperature hold time
SS316L stainless steel product-contact surfaces - pharmaceutical grade
Electric immersion heating elements - 4 × 10 kW for rapid heat-up
Temperature control with PT100 sensor probe
Atmospheric pressure operation
Sanitary connections for supply and return lines
Compatible with GDR40 series hot water circulation pumps
Smooth polished exterior - easy to wipe down and maintain

Technical Specifications

Parameter	Specification
Nominal Capacity	800L/1,000L/1,500L/2,000L/5,000L
Product Contact Material	SS316L stainless steel
Operating Pressure	Atmospheric
Temperature Range	25 – 100 °C
Typical Set Point	85 – 90 °C (for cleaning use)
Heating Power	4 × 10 kW electric immersion elements (40 kW total)
Temperature Sensor	PT100 probe
Insulation	Double-wall jacket with thermal insulation
Compatible Circulation Pump	GDR40 series hot water pump

Typical Applications

Hot water supply for gelatin melting tank cleaning or production gel. (water-jacketed preparation vessels)
Clean-in-place (CIP) hot water supply for process piping and tanks
General process hot water for ancillary production equipment
Installation in utility rooms or preparation area support zones
Companion unit for TRNJ-2 and JSZ-2 series gelatin melting systems

Compliance & Construction

SS316L product-contact construction - pharmaceutical grade material
Hygienic design with smooth internal surfaces and drainable bottom
GMP-appropriate for pharmaceutical facility utility systems
Material certificates available on request
Standard documentation: operation manual, maintenance checklist, electrical schematic

Related Equipment

Gelatin Melting & Mixing Tank - primary equipment served by hot water supply
Pharmaceutical Preparation & Mixing Tanks - additional process vessels requiring hot water cleaning
Tumble Cage Washing System - equipment cleaning applications

Custom capacities and alternative heating configurations (steam coil, heat exchanger) available on request for larger facility utility systems.
